Thermic Edge offer a range of All Ceramic heating of samples up to 1200˚c. A CCC element housed within a Ceramic body with a range of sample plate sizes to suit any specimen with the optional extra of sample clips.
Additional features such as sample clips can be added or should you wish have the heater made to match the sample shape and of course larger size are available than the ceramic heater displayed here.
| Heater Hot Zone Sizes | 25mm x 50mm |
|---|---|
| Heater maximum top plate temperature | 1200˚c |
| Max element temperature | 1200˚c |
| Cold resistance | 1.4Ω |
| Heater body material | BNS26 |
| Heater top plate material | ABN1000 |
| Thermocouple type | K Type, 0.5m in vacuum cables supplied |
| In vacuum cable lengths | 0.5m |
| Environment | High Vacuum |
| Heater orientation | Horizontal |
| Substrate mounting | Sample Clips on top plate |
| Element type | CCC |
| Maximum operating current | 32A |
Thermic Edge All Ceramic Sample Heaters are used for heating samples up to 1200˚c. They use a CCC element housed within a ceramic body, with sample plate sizes available to suit different specimens.
The heater can reach a maximum top plate temperature of 1200˚c, with a maximum element temperature of 1200˚c.
The heater hot zone size is 25mm x 50mm.
The heater body is made from BNS26, and the heater top plate is made from ABN1000.
Yes. The All Ceramic Sample Heater is suitable for high vacuum use and includes 0.5m in vacuum cables.
Yes. Sample clips can be added as an optional extra, and samples can be mounted using sample clips on the top plate.
Yes. Thermic Edge can provide heaters made to match the sample shape, and larger sizes are available than the ceramic heater displayed here.
The heater is supplied with a K Type thermocouple and 0.5m in vacuum cables.
For related sample heating options, view the Sample Heaters page or the wider Thermic Edge heaters directory.
Useful details include the required sample size, sample shape, whether sample clips are needed, required heater size, operating environment, thermocouple requirements and cable length requirements. You can contact Thermic Edge through the contact page or email sales@thermic-edge.com.
